Product Details
Highlight

Five Optical Channels Thermal Imaging Binoculars

,

Multi Function Thermal Imaging Binoculars

,

Multi Function Binoculars Thermal Imaging

Leave a Message
Product Description


                                  Five Optical Channels Multi-Function Binocular

TH-D5 Five Optical Channels Multi-Function Binoculars Thermal Imaging Binoculars 0

Infrared, low light, visible light, laser rangefinder and laser pointer in one

High-resolution 1280×1024 OLED display screen

Support for GPS, BD localization

Work continuously for more than 8 hours

Wi-Fi data transmission

Waterproof grade IP67

 Products Description

The TH-D5 Five Optical Channels Multi-function Binocular with Five Optical Channels is an intelligent observation device that combines infrared low-light visible light, laser ranging instrument, into one product.

 It has a built-in positioning module, a digital magnetic compass, and a laser rangefinder, making it an extremely versatile and efficient tool for observing and exploring. The five optical channels enable you to switch between infrared, low-light, and visible light modes, providing crystal clear images and enhancing your view.

 The laser rangefinder function provides accurate distance measurements, making it easier to determine the distance between yourself and the object you are observing. The laser pointer enables you to point to areas of interest and guide your fellow observers.

 The TH-D5 Five Optical Channels Multi-function Binocular with Five Optical Channels is constructed using high-quality materials and incorporates advanced technology to provide superior performance in challenging environments. With excellent durability and a compact design, it is portable and perfect for on-the-go use.

 In conclusion, the TH-D5 Five Optical Channels Multi-function Binocular with Five Optical Channels is an exceptional observation device. It is versatile, efficient, and precise, making it an ideal tool for outdoor enthusiasts, hunters, security personnel. Its advanced features, including the laser rangefinder, and positioning module, make it a must-have for any situation where precision observation is critical.

TH-D5 Five Optical Channels Multi-Function Binoculars Thermal Imaging Binoculars 1TH-D5 Five Optical Channels Multi-Function Binoculars Thermal Imaging Binoculars 2

TH-D5 Five Optical Channels Multi-Function Binoculars Thermal Imaging Binoculars 3

Technical Parameters

Infrared Thermal Imaging



Resolution

640×512, 12 μm

Spectral Band

8~14 μm

FOV

6.1°×4.8°

Low-Light Imaging



Resolution

750×600

Low Illumination Capability

0.001 lux

FOV

6.8°×5.5°

Visible Light Imaging



Resolution

4.6 megapixels

FOV

4.6°×3.7°

Laser Rangefinder



Wavelength

1535 nm

Maximum Measurement Range

≥6 km

Minimum Measurement Range

≤50 m

Measurement Accuracy

2 m

Location Module



Location Mode

BD, GPS

Horizontal Location Accuracy (Cep)

5 m

Elevation Location Accuracy (Pe)

10 m

Digital Magnetic Compass



Magnetic Azimuth Measurement Range

0~360°

Magnetic Azimuth Measurement Accuracy

0.5°

Pitch Angle Measurement Range

-90°~+90°

Pitch Angle Measurement Accuracy

0.4°

Inclination Angle Measurement Range

-180°~+180°

Inclination Angle Measurement Accuracy

0.5°

Laser Pointer



Wavelength

830 nm

Security Level

5 mW, Class IIIA

Display



Resolution

1280×1024

External Interface



Aviation

DC/USB/PAL/RS232

Display

HDMI

Wireless Transmission

WIFI

Overall Device



Storage

64G

Ocular Lens Diopter

-4~+4

Weight

2.1 kg

Operating Time

≥8 h

Operating Temperature

-40°C~+55°C

Storage Temperature

-55°C~+70°C

Waterproof Grade

IP67
