Aviation Pistol Red Dot Sight 32mm×23mm Red Dot Vision Aluminum Alloy 7075
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Highlight | aviation pistol red dot sight,32mm×23mm red dot vision,pistol red dot sight 32mm×23mm |
||
|---|---|---|---|
Product Description
Aviation Pistol Red Dot Sight 32mm×23mm Red Dot Vision Aluminum Alloy 7075
Product Overview
The RS9-KR01 Red Dot Sight is a compact, high-performance optical device designed for fast target acquisition in tactical, competitive, and hunting scenarios. Engineered with aviation-grade aluminum alloy 7075, it offers exceptional durability and precision.
Key Features
- Compact Design: Side-mounted CR2032 battery for reduced size and weight
- Versatile Reticle Options: Three aiming patterns (red dot, red circle, dot circle combination)
- Precision Engineering: Advanced extinction pattern eliminates stray light
- Military-Grade Construction: CNC-machined from 7075 aluminum alloy with hard black oxide surface treatment
- Environmental Resistance: Waterproof (IP67), fog proof, and shockproof
Performance Specifications
| Optical Properties | |
|---|---|
| Magnification | 1X |
| Viewport Size | 32mm×23mm |
| Aiming Patterns | Red Dot/Red Circle/Red Dot & Circle |
| Red Dot Size | ≤2MOA |
| Parallax | ≤2MOA |
| Electrical Properties | |
| Battery | CR2032 |
| Continuous Operation | ≥10,000 hours (medium brightness) |
| Brightness Levels | 9 daytime/2 night vision |
| Mechanical Specifications | |
| Material | Aviation Aluminum Alloy 7075 |
| Adjustment Range | ±40MOA (elevation/azimuth) |
| Adjustment Accuracy | 0.5MOA per click |
| Mounting | Picatinny Rail |
Environmental Durability
- Operating Temperature: -40℃ to +65℃
- Storage Temperature: -45℃ to +70℃
- Waterproof Rating: IP67 standard
